3M MV18-10R/LX Ring Vinyl Insulated Brazed Seam Ring Tongue Terminal, Red, 22-18 AWG (7000133316) (500 Pack)
Bulk Pricing Available
Bulk Pricing Available
Need to place a large order? Request a quote
3M MV18-10R/LX Ring Vinyl Insulated Brazed Seam Ring Tongue Termina...
Description
Description
3M 7000133316 Description
3M Scotchlok vinyl insulated brazed seam ring tongue terminal provides reliable electrical connections with easy wire insertion, corrosion resistance, and a standard ring tongue that fits around a stud.
3M 7000133316 Includes
- (500) 3M Scotchlok vinyl insulated ring tongue terminals, MV18-10R/LX
3M 7000133316 Features
- Vinyl insulated brazed seam barrel for reliable and safe performance
- Funnel designed polyvinyl chloride sleeve helps provide easy wire insertion
- Standard style ring tongue fits around the stud for secure mounting
- Electrolytic copper construction helps provide good conductivity
- Tin plated finish helps resist corrosion
- Temperature range -40 to 221 Degree F (-40 to 105 Degree C)
- 600V rated for building wire and 1000V for signs fixtures or luminaires
- UL Listed and CSA Certified
- RoHS 2011/65/EU compliant
3M 7000133316 Specifications
| Terminal Type | Ring |
| Insulation Material | Vinyl |
| Product Color | Red |
| Minimum Conductor Size | 22 AWG |
| Maximum Conductor Size | 18 AWG |
| Maximum Operating Temperature | 105 Degree Celsius |
| Overall Length | 0.93 in |
| Overall Width | 0.31 in |
| Connection Width | 0.19 in |
| Material | Electrolytic copper |
| Finish | Tin plated |
| Voltage Rating | 600V building wire 1000V signs fixtures or luminaires |
| Certifications | UL Listed CSA Certified |
| Compliance | RoHS 2011/65/EU |
