3M BSV10Q Highland Vinyl Insulated Butt Connector Terminal, AWG 12-10, Yellow (7000133654) (250 Pack)
Bulk Pricing Available
Bulk Pricing Available
Need to place a large order? Request a quote
3M BSV10Q Highland Vinyl Insulated Butt Connector Terminal, AWG 12-...
Description
Description
3M 7000133654 Description
3M Highland vinyl insulated butt splice connector provides a secure crimp connection for 12 to 10 AWG wire. The electrolytic copper terminal is tin plated to resist corrosion and is rated up to 600V with an operating temperature range of -40 to 221 Degree Fahrenheit.
3M 7000133654 Includes
- (250) - 3M 7000133654 C3SD Vinyl Insulated Butt Connector Terminal BSV10Q, AWG 12-10
3M 7000133654 Features
- Vinyl insulated, butted seam barrel helps ensure a secure crimp connection
- Color coded design for quick wire size identification
- Funnel designed PVC sleeve helps guide wire into position
- Built in wire stop helps ensure correct positioning
- Electrolytic copper terminal with tin plating for corrosion resistance
- Accommodates 12 to 10 AWG conductors
- Rated up to 600V for building wire and 1000V for signs fixtures or luminaires
- Operating temperature range -40 to 221 Degree Fahrenheit
- UL Listed and CSA Certified
- RoHS 2011/65/EU compliant
3M 7000133654 Specifications
| Part Number | BSV10Q |
| Terminal Type | Butt Connector |
| Connector Type | Butt |
| Conductor Size | 12 to 10 AWG |
| Insulation Material | Vinyl |
| Body Material | Copper Alloy |
| Barrel Style | Butted |
| Barrel Inside Diameter | 0.25 Inch |
| Overall Length | 1.02 in |
| Maximum Recommended Voltage Rating | 600 V |
| Maximum Operating Temperature | 105 Degree Celsius |
| Maximum Insulation Outside Diameter | 0.145 in |
| UL File Number | E23438 |
| CSA File Number | LR22190 |
| RoHS Compliance | RoHS 2011/65/EU compliant without exemption |
