The Complete Guide to 3M Welding Protection: Helmets, Filters, Lenses & Accessories

If you've spent any time welding, you already know that your face and eyes aren't something you get a second chance with. Arc flash, spatter, UV radiation, infrared light, heat, and grinding sparks are all part of the job. The gear you strap on your head needs to handle all of it, every single time.

That's where 3M comes in. Their Speedglas line has been the go-to for professional welders for decades, and for good reason. This isn't bargain-bin gear. It's built for guys who weld for a living and can't afford to cut corners on protection.

This guide is going to walk you through everything in the 3M welding protection lineup. We'll cover the full range of welding helmets, auto-darkening filters, passive lenses, lens shades, headgear, face seals, neck covers, batteries, lighting, magnification, starter kits, and protective plates. By the time you're done reading, you'll know exactly what you need and why.

3M has been making safety equipment for industrial workers for over a century. The Speedglas brand specifically goes back to 1981 when auto-darkening welding helmets were first introduced commercially. Today, Speedglas helmets are used in shipyards, fabrication shops, pipeline work, construction sites, and anywhere else serious welding happens.

What separates Speedglas from the pack is consistency. The auto-darkening filters switch from light to dark in as fast as 0.1 milliseconds on some models. The optical quality is graded to the highest international standards. And the helmet systems are designed to integrate with respiratory protection when you need it.

Let's get into the specific product categories so you know what's available and what each one does.

The welding helmet is the starting point. Everything else attaches to it or works with it. 3M makes helmets both with and without auto-darkening filters (ADF) built in, so you can buy the shell and add the filter you want, or grab a complete ready-to-weld package.

The G5-03 Pro is 3M's current flagship welding helmet series, and it's the one most professional welders should be looking at. It's built to work with the latest G5-series auto-darkening filters and the G5 task light kit. The helmet shell itself is designed for durability, comfort, and compatibility with respiratory protection systems.

Here's what's available in the G5-03 lineup:

• 3M G5-03 Pro Welding Helmet (10-0100-00) is the base model helmet shell without an ADF. You pick the filter separately, which gives you flexibility to get exactly the lens you need.
• 3M G5-03 Pro Helmet with Hard Hat (10-0100-00HH) combines the welding helmet with an integrated hard hat. If you're on a job site where head protection is required, this lets you weld without swapping headgear.
• 3M G5-03 Pro Helmet with Safety Helmet (10-0100-00SH) pairs the welding helmet with a full safety helmet configuration. This is the setup for guys who need both welding eye protection and head protection on the same job.
• 3M G5-03 Pro Helmet with G5TW ADF (10-0100-30TW) comes as a complete package with the G5 True-View auto-darkening filter already installed. If you want the best optical clarity 3M currently makes, this is a strong option to look at.
• 3M G5-03 Pro Helmet with G5VC ADF (10-0100-30VC) includes the G5 Variable Color filter. This ADF gives you color control across the darkening range for better bead visibility and weld pool reading.
• 3M G5-03 Pro-Air Welding Helmet (45-0099-35) is the air-fed version of the G5-03 system. This connects to a powered air-purifying respirator (PAPR) for full respiratory protection alongside your welding shield. If you're welding on stainless, coated metals, or in confined spaces, respiratory protection isn't optional.

The Speedglas 9100 is one of the most recognized welding helmet series in the industry. It's been a workhorse for professional welders across all types of applications and still has a strong following for good reason.

• 3M Speedglas 9100FX Helmet with 9100X ADF (06-0600-20SW) features the FX flip-front design, which lets you flip up the helmet while keeping the auto-darkening filter in place. This is useful when you need to quickly move between welding and inspection or grinding without removing your helmet entirely.


• 3M Speedglas 9100 Helmet with ADF 9100X (06-0100-20SW) is the standard 9100 helmet with the 9100X filter included. The 9100X ADF covers shade 8 through 13 and has a larger viewing area than basic models.

3M G5-02 Helmet with Curved ADF (08-0100-50iC) features a unique curved lens design that provides a wider, more natural field of view than flat-lens helmets. The curved optics reduce distortion at the edges of your view, which makes a real difference on long welds or detailed work.

For welders who work with hazardous fumes, galvanized materials, or in enclosed environments, 3M offers full helmet systems that combine welding eye protection with respiratory protection:

The 3M Versaflo M-409SG and M-153SG Helmet Assemblies with Welding Shield integrate a welding shield with the Versaflo M-Series PAPR system. These setups provide both arc protection and continuous clean air delivery to the welder. If respiratory protection is required on your job, these systems remove the hassle of wearing a separate respirator under your welding hood.

The 3M 9000 Welding Helmet (04-0112-00NC) and 3M 9100MP Helmet with Hard Hat (27-0099-35SW) round out the selection for specific application needs.

The auto-darkening filter is the heart of any modern welding helmet. It's the lens that switches from clear to dark the instant you strike an arc, then switches back when you stop welding. A good ADF means you can position your work with the lens clear, then weld without flipping anything up or down.

Here's what the key specs mean:

• Switching Speed: Measured in milliseconds (ms). The faster, the better. Speedglas ADFs switch at 0.1ms on many models, which is fast enough that you won't notice the delay. Slow ADFs can let a flash of unfiltered arc light through, which is both uncomfortable and potentially harmful over time.
• Shade Range: This tells you what welding processes the filter supports. A wider shade range means you can weld at higher amperage and still have the right darkness level.
• Optical Class: 3M ADFs are rated to optical classes for distortion, diffusion of light, variations in luminous transmittance, and angle dependence. Higher ratings mean better visual clarity.

Here's a breakdown of the Speedglas ADFs available:

• 3M Speedglas 9100V ADF (06-0000-10) covers shade 5 through 13. The 9100V is a well-rounded filter for MIG, TIG, and stick welding at most standard amperage levels. It's been a reliable choice for years in professional shops.
• 3M Speedglas 9100X ADF (06-0000-20) expands the viewing area compared to the 9100V and keeps the same shade 5 to 13 range. The wider lens gives you a better view of your work and the surrounding area, which reduces repositioning during long welds.
• 3M Speedglas 9100XX ADF (06-0000-30) has the widest viewing area in the 9100 series. If you're doing precision work or if a larger field of view matters to you, the 9100XX is the top-of-the-line option in the standard 9100 lineup.
• 3M Speedglas 9100XXi ADF (06-0000-30I) adds external controls to the 9100XX, so you can adjust shade settings without taking off your helmet. It also supports a camera connection port for weld documentation. This is the most feature-rich option in the 9100 series.
• 3M Speedglas G5 ADF (46-0000-30VC) is designed for the G5-series helmets and features variable color technology. This filter gives you the ability to fine-tune color perception during welding so you can read the weld pool more accurately.
• 3M Speedglas ADF 100V (37246) is a more entry-level auto-darkening filter designed for the Speedglas 100 series helmets. It covers shade 8 through 12 and is a solid option for lighter-duty welding applications.
• 3M Speedglas 9002NC ADF (04-0000-21NC) fits older 9000 series helmet shells and is available for those still running that platform.

Not every welding situation calls for an auto-darkening filter. Passive welding lenses are fixed-shade lenses that stay at one darkness level. They're simpler, lighter, and less expensive than ADFs. Many welders keep passive lenses on hand as backups or use them for specific applications.

The right shade depends on the welding process and amperage you're running. Here's a general guide:

• Shade 10: Suitable for MIG welding at lower amperage ranges and TIG welding up to around 100 amps.
• Shade 11: Works for MIG welding at mid-range amperage and TIG up to around 150 amps.
• Shade 12: Good for higher-amperage MIG and TIG processes.
• Shade 13: Used for high-amperage stick welding and heavy MIG applications.

3M offers passive Speedglas lenses in all these shades:

• 3M Speedglas Passive Lens Shade 10 (06-0005-P10)
• 3M Speedglas Passive Lens Shade 11 (06-0005-P11)
• 3M Speedglas Passive Lens Shade 12 (06-0005-P12)
• 3M Speedglas Passive Lens Shade 13 (06-0005-P13)
• 3M Speedglas Lens Assembly Shade 10 (06-0000-P10)

For grinding, cutting, or work that doesn't involve an arc but still generates flying debris and spatter, a welding face shield is a more practical option than a full welding helmet. Face shields give you full facial coverage without the weight of a complete helmet system.

3M Polycarbonate Faceshield Window, Shade 5.0 (82706-10000 W96IR5) is a shade 5 window designed to protect against infrared radiation during tasks like torch work, cutting, and grinding on hot materials. It comes in packs of 10, which makes it a smart buy for shops that go through windows regularly. Shade 5 is lighter than welding shade levels, so it's designed for processes that produce heat and IR but not the intense UV of an electric arc.

Your ADF or passive lens needs to be protected from spatter and scratches by protective plates on both the inside and outside. These are consumable items, meaning you'll replace them regularly as part of routine helmet maintenance. Running a helmet with scratched or spatter-coated protective plates cuts down your visibility and puts extra strain on your eyes.

Outside plates face the weld and take the most abuse. 3M offers standard and high-temp versions for the 9100 series:

• 3M Speedglas 9100 Outside Plate, High Temp (06-0200-53) is rated for high-temperature environments. If you're welding overhead, doing heavy fabrication, or working in hot shop conditions, the high-temp plate holds up better against spatter without warping or distorting. Also available in a 50-pack (06-0200-53-B) for shops that go through them fast.


• 3M Speedglas 9100 Outside Plate, Standard (06-0200-51) covers everyday welding conditions and is a cost-effective choice for most applications.

3M also makes outside plates for the 9000 series (04-0270-04, 04-0270-01, 04-0270-03 HD), for the 100 series (37244, 07-0200-51), and for the SL series (05-0250-00).

Inside plates protect the ADF from dust, sweat, and debris on the welder's side of the lens. They're often overlooked, but they matter.

3M Speedglas 9100XX Inside Plate (06-0200-30) fits the 9100XX filter. Make sure you match your inside plate to the correct ADF model. 3M also makes the 9100X Inside Plate (06-0200-20)  and the 9000 Series Inside Plate (04-0290-00) for those platforms.

A helmet that doesn't fit right is a helmet that gets taken off. Headgear is what keeps the helmet comfortable and properly positioned through a long shift. If you're replacing worn-out parts or upgrading comfort on an existing helmet, 3M has everything you need.

3M Speedglas 9100 Welding Headband (06-0400-52) is the standard headband for the 9100 series. It's adjustable and keeps the helmet secure during active work.

The 3M Speedglas Sweatband Fleece (07-0024-02) comes in a 2-pack and sits against your forehead. It absorbs sweat and keeps it from running into your eyes during hot work. Replace it regularly since a saturated sweatband is both uncomfortable and unsanitary.

The 3M M-953 Speedglas 9100 Headband Back Part and 3M Speedglas G5-01 Comfort Head Rest (46-0400-55) give you replacement and upgrade options for the back-of-head support on different helmet platforms.

For the SL series, the 3M Speedglas SL Headband Assembly Kit (05-0660-00) gives you a complete replacement headband assembly.

The 3M Speedglas 100 Series Front Frame in Silver (07-0212-00SV) is an accessory part for those running the Speedglas 100 series that lets you update or replace the front frame if it gets damaged

If you're welding in environments with fumes, fine particles, or you're using a powered air-purifying respirator with your helmet, the face seal is the interface between the helmet and your face. A worn or missing face seal defeats the purpose of the respiratory protection.

3M makes face seals specific to each helmet system:

• 3M Speedglas Face Seal for 9100MP (27-0099-28) seals the 9100MP series when used in respiratory protection mode.
• 3M Speedglas Face Seal for 9100 Air (25-0099-28) fits the 9100 Air-fed models.
• 3M Speedglas Face Seal for 9100 FX-Air (25-0099-28)fits the FX-Air variant.
• 3M G5-01 Speedglas Face Seal (7100213918) is designed for the G5-01 helmet system.


Beyond face seals, 3M offers neck and ear protection for extended coverage during heavy welding:

• 3M Speedglas Extended Coverage Ear/Neck (06-0500-52) adds soft protection to the sides and back of the neck. It's useful for overhead work or environments where spatter comes from unexpected angles.
• 3M Speedglas Throat and Neck Coverage (27-0099-85) protects the front of the throat and neck, which is an area that often goes unprotected in standard welding setups.
• 3M Speedglas G5-01 Leather Neck Cover (46-0700-67) is a durable leather option that stands up to spatter and repeated contact better than fabric alternatives. Leather is a smart choice for high-spatter welding like stick or flux-core.
• 3M Speedglas G5-01 Rigid Neck Cover (46-0700-65) provides a harder shield for the neck area, giving maximum protection in demanding environments.
• 3M Speedglas Extended Headcover (06-0700-82) covers more of the top and back of the head and pairs with the 9100 series for environments with heavy spatter or radiant heat.

Standard welding helmets give you a view straight ahead, but some work environments require peripheral vision. The 9100 series offers side window options and grinding accessories to expand your protection and visibility.

• 3M Speedglas 9100 FX/FX-Air Wide-View Grinding Visor (06-0700-54) is a shade 5 grinding visor that flips down over the front of the 9100 FX helmet when you switch from welding to grinding. It gives you full coverage for grinding operations without changing helmets.
• 3M Speedglas 9100 SideWindows Coverplate (06-0500-53) protects the side windows on the 9100 series from spatter and scratches. Replace them when visibility through the side windows starts to degrade.
• 3M Speedglas 9100 FX/FX-Air SideWindow Covers (06-0700-73) are the protective covers for the side windows on FX and FX-Air models.
• 3M Speedglas 9100 FX/FX-Air Front Panel in Chrome (06-0700-63) and the 3M Speedglas 9100 Front Panel in Silver (06-0300-55) are replacement and cosmetic front panels for the 9100 FX series. If your front panel gets damaged or you just want to freshen up the look, these are direct replacements.

Auto-darkening filters need power to operate. Most Speedglas filters run on a combination of solar cells and batteries. The solar cells extend battery life significantly, but you'll still need to replace the batteries eventually.

• 3M Speedglas CR2032 Batteries (04-0320-00) are the standard replacement batteries for most Speedglas ADF units. The CR2032 is a common lithium coin cell battery. If your ADF starts behaving inconsistently or isn't switching reliably, battery replacement is usually the first thing to check before assuming there's a bigger problem.
• 3M Speedglas Battery Holder (06-0400-55) fits the 9100 series and 3M Speedglas Battery Holder (04-0380-00) fits the 9000 series. These are the housings that hold the batteries in place within the filter unit.
• 3M G5-01 Short Helmet Power Cable (46-0500-03) connects the G5-01 helmet to a power source when running in an air-fed or powered configuration.

Welding in low-light conditions is a real challenge. Even if you can see the arc clearly, setting up your work, reading marks, and checking bead quality between passes in a dark shop or a confined space is difficult. 3M's task light kits attach directly to the helmet and give you hands-free work lighting.

3M G5-01 Task Light Kit (46-0500-01) is designed for the G5-01 helmet platform and mounts without tools. The light positions to illuminate your work area directly in front of you.

3M G5 Task Light Kit (10-0500-01) fits the G5-series helmets. If you're regularly welding in poorly lit areas, shipboard work, pipe fabrication in tight spaces, or underground utility work, a task light pays for itself quickly in reduced setup time and fewer weld quality issues from poor visibility.

As you get older, close-up work becomes harder. Reading the weld pool clearly matters for quality, and if you're straining to see detail, your welds are going to show it. Magnification plates slot into your Speedglas helmet behind the outside protective plate and give you a close-up boost without needing reading glasses under your helmet.

3M Speedglas Magnification Plate 2.0X (06-0500-57) provides a 2.0 diopter boost. This is a good starting point for welders who are just starting to notice they need a little extra close-up help.

3M Speedglas Magnification Plate 2.5X (06-0500-58) steps it up to 2.5 diopters for more significant close-up magnification. It fits the standard 9100 series helmets. For the G5-02, the G5-02 Magnification Plate 2.5X (08-0500-58) is the right fit.

If you're setting up a new helmet or just did a full inspection and found you're low on consumables, the starter kits are the most efficient way to get what you need in one shot. Each kit includes a curated set of protective plates and other key components specific to the helmet platform.

• .3M Speedglas Starter Kit 9100V (06-0201-10) includes the essentials for the 9100V filter platform.
• 3M Speedglas Starter Kit 9100X (06-0202-20) covers the 9100X platform.
• 3M Speedglas Starter Kit 9100XX (06-0202-30) is for the top-tier 9100XX and 9100XXi filters.
• 3M Speedglas G5-01 Starter Kit (45-1101-99) gives you the components you need to set up or replenish a G5-01 helmet.

Buying a starter kit instead of individual components usually saves you money and eliminates the headache of hunting down individual part numbers for your specific helmet model.

The Speedglas 9100MP is the version of the 9100 series that integrates with powered air respirators. It has its own set of system-specific accessories:

1. 3M Speedglas 9100MP Flip-Up Mechanism (27-0099-53) is the flip mechanism that allows the welding shield to be raised without removing the respiratory connection. If this part wears out, it can be replaced separately without buying an entire new helmet.
2. 3M Speedglas 9100MP Pivot Kit (27-0099-52) contains the pivot components for the 9100MP. Over time, the pivot can wear or break, especially with heavy daily use. Having a spare on hand keeps downtime to a minimum.
3. 3M Speedglas 9100MP Outer Shield (27-0099-68) is the outer protective shield for the 9100MP that protects the ADF and front of the helmet during grinding and general work.
4. 3M Clip-On Welding Shield Kit (7990/7990-AM) is a unique accessory that clips onto existing safety eyewear to provide basic welding protection. It's not a replacement for a proper welding helmet, but it works for quick tack welds or low-amperage work when setting up a full helmet isn't practical.

With this many options, it helps to think through your situation before buying. Here's a straightforward way to narrow it down:

1. What type of welding are you doing? MIG, TIG, stick, flux-core, and plasma cutting all have different shade requirements. TIG at low amperage might only need a shade 10, while heavy stick might need shade 13. Make sure your ADF or passive lens covers your amperage range.
2. Do you need respiratory protection? If you're regularly welding stainless steel, galvanized metal, or any coated material, fume exposure is a real concern. Look at the G5-03 Pro-Air, the 9100MP, or the Versaflo helmet assemblies for integrated solutions.
3. Do you need a hard hat or safety helmet integration? Job site regulations sometimes require both welding eye protection and head protection simultaneously. The G5-03 Pro Hard Hat and Safety Helmet versions solve this without doubling up equipment.
4. How much do you weld each day? If you're welding all day every day, invest in a high-quality ADF with fast switching speed and excellent optical clarity. Your eyes will thank you at the end of a long shift. The 9100XXi and G5 VC are the right choices for high-volume welders.
5. Are you working in tight spaces or low light? Add the task light kit to your setup. It's one of those accessories that seems optional until you've used it and can't imagine going back.
6. Are you having trouble seeing close-up detail? A magnification plate is far more practical than trying to wear reading glasses inside a welding helmet.

A well-maintained helmet lasts longer and protects you better. Here's what you should be doing regularly:

• Check your protective plates every day. If the outside plate has heavy spatter buildup or visible scratches that affect your view, replace it. It's a cheap fix that makes a big difference in visibility.
• Replace your inside plate when it gets foggy or scratched. The inside plate protects your ADF from the inside. A scratched inside plate makes it harder to see clearly during the weld.
• Inspect your ADF regularly. Test the darkening function by looking at a bright light source and verifying the filter activates. If it's slow to respond or doesn't darken to the correct shade, check the battery first, then the sensitivity and delay settings.
• Replace batteries annually at a minimum. Even if your ADF seems to be working fine, fresh CR2032 batteries are cheap insurance against an unexpected failure during a weld.
• Keep face seals and headgear clean. Wipe down face seals regularly with a damp cloth. Replace sweatbands and headbands when they show wear or lose their cushioning.
• Check the headband and pivot mechanisms. Loose or broken headband components mean the helmet won't sit correctly. 3M makes replacement parts for every component, so there's no reason to run a helmet that doesn't fit right.

Your welding protection is one of the most important investments you make in your trade. A good helmet doesn't just protect you from arc flash and UV radiation, it makes you a better welder by giving you a clear, undistorted view of your work. The 3M Speedglas lineup is built for exactly this purpose.

Whether you're running a full G5-03 Pro system with task lighting and an air-fed respirator or you just need a new set of passive lenses and a replacement headband for your 9100 series, ProWork Supply has the full lineup available.
